Key Features： • PCIe Gen4 16Gb/s External Connectivity • High Performance with 16Gb/s PCIe Data Transfer Rates • PLX PEX88032,B0 Switch Chip • Quad Mini-SAS HD (SFF-8674) External Connectors • x16 Gen4 Host Interface • x1, x2, x4, x8, x16 External Port Configurations • Base Mode and Synthetic Mode • Compliant with PCI SIG External Cabling Revision 4.0, Version 0.3 • Heartbeat LEDs • HHHL PCIe CEM Form Factor • Active Optical Cable Support Key Advantages： • External UART with CLI • FW Upgradeable • Supports CMI PCI SIG Messaging Between Upstream and Downstream Ports • Software Configurable Sideband Signals – PCI SIG Compliant – 100Mhz Differential PCIe Reference Clock – Downstream PCIe Resets • Downstream Port Containment (DPC) and eDPC • 100% Passive Cooling (No Active Fans Required) • PCIe Clocking Options – SRIS/SRNS, NON-SRIS, Common-Clocking |
